Thesycon Port Devices Driver

USB Audio 2.0 Class Driver for Windows

  1. Thesycon Driver 4.86 Download
  2. Thesycon Port Devices Driver Device
  3. Thesycon Port Devices Driver Updater
  4. Thesycon Usb Driver
  5. Thesycon Port Devices Driver License Test

Thesycon's device driver for USB CDC/ACM compliant devices a serial port emulation on Windows 10, 8.1, 8 and 7 by implementing a serial link emulation protocol on USB. USB CDC/ACM Class Driver for Windows 10 - Virtual Com Port Class Driver TL-USBCOM Driver for Windows 10, 8.1, 8 and 7 Features Supported Platforms Demo Prices. Thesycon has successfully completed numerous Windows device driver projects, including for USB and FireWire devices, or sophisticated, high-speed PCI/PCI Express DMA devices. We have great experience in creating complex kernel-mode drivers such as bus drivers, filter drivers, network drivers and software-only drivers.

FeaturesSupported PlatformsDemoPrices

Thesycon’s USB audio class driver TUSBAudio targets USB audio devices for professional and semi-professional use and highest quality audiophile HiFi systems. The driver supports devices which are compliant to the USB Audio 2.0 or USB Audio 1.0 device class specification. The driver provides an ASIO 2.3.1 compliant software interface and integrates with Windows as a standard WDM/DirectX compatible sound device. If the device provides MIDI features the driver exposes standard Windows MIDI ports.

Thesycon port devices drivers

To meet professional audio requirements, the audio class driver is optimized for low latency and low CPU load. Buffer depths can be adjusted by the user to optimize settings for a given computer. The driver implements a transparent (bit-perfect) playback and recording data path.


  • supports Audio class 1.0 and Audio class 2.0 devices
  • supports USB 2.0 full speed and high speed, and USB 3.0 super speed or higher
  • supports standard sampling rates (depending on device capabilities):
    44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz, 352.8 kHz, 384 kHz, 705.6 kHz, 768 kHz, 1411.2 kHz, 1536 kHz
  • supports USB Audio Type I sample formats:
    PCM 16 bit, PCM 24 bit, PCM 32 bit, FLOAT 32 bit
  • supports stereo and multi-channel configurations with as many channels as the device implements


  • ASIO 2.3.1 compliant driver DLL
  • sample formats (depending on device capabilities): PCM 24 bit, PCM 32 bit
  • bit-perfect playback and recording through ASIO
  • playback mix (simultaneous ASIO and WDM playback)
  • supports both 32-bit and 64-bit ASIO host applications
  • multi-client support (multiple ASIO applications in parallel)
  • configuration of ASIO buffer depth via driver control panel
  • ASIO DSD mode supported (playback and recording), see below DSD Support
Thesycon usb driver

The TUSBAudio driver uses ASIO Driver Interface Technology and the Steinberg ASIO SDK. ASIO is a trademark and software of Steinberg Media Technologies GmbH.

WDM/DirectX Features

Thesycon Driver 4.86 Download

  • standard Windows sound interfaces: MME, DirectSound, WASAPI
  • stereo and multi-channel playback and recording sound devices (depending on device capabilities)
  • flexible sound device configuration, for example:
    8-channel unit can either be exposed as 7.1 or 4 x stereo playback
  • bit-perfect playback and recording through WASAPI
  • volume and mute control through Windows standard GUI (depending on device capabilities)
  • jack sensing (depending on device capabilities)
  • PCM 16 bit, 24 bit, and 32 bit sample format (depending on device capabilities)

DSD Support

  • native DSD mode through ASIO (see above)
  • DSD over PCM (DoP) supported through ASIO and WDM
  • DSD sample rates: DSD64 (2.8MHz), DSD128 (5.6MHz), DSD256 (11.3MHz), DSD512 (22.6MHz), DSD1024 (45.2MHz)

MIDI Features

  • Windows compliant MIDI input and output ports (depending on device capabilities)
  • Multiple applications can share a MIDI input port.
  • Optionally, multiple applications can share a MIDI output port.

Virtual Channels Add-on

Thesycon port devices driver device

The Virtual Channels Add-on is an optional component of the TUSBAudio driver and has to be licensed additionally.

  • virtual input or output channels can be defined (e.g. loopback channels)
  • virtual WDM sound devices can be built from virtual channels
  • arbitrary signal routing between physical and virtual channels can be configured
  • routing and weights are fixed (not dynamically configurable through API)

Thesycon Port Devices Driver Device

Mixer Add-on

The Mixer Add-on is an optional component of the TUSBAudio driver and has to be licensed additionally.

  • driver implements complete mixer matrix for all input and output channels
  • any mixer weight can be controlled through API at runtime
  • SDK included, contains sample application for mixer control
  • virtual input or output channels can be defined (e.g. loopback channels)
  • virtual WDM sound devices can be built from virtual channels
  • application examples: monitor mix, loopback channels, channel swap, balance, etc.
  • The driver will be delivered fully customized for licensee’s product.
  • Customization includes USB VID/PID, file names, text strings, etc.
  • Windows 10 version of the driver is signed with Microsoft Attestation signing.
  • Windows 7/8 version of the driver is signed with Thesycon’s code signing certificate.
  • Driver Customization Kit add-on: The Driver Customization Kit enables licensee to customize the driver by themselves.
  • Wizard style user interface for interactive use
  • Command line interface (silent mode) for integration into overall software setup
  • Customization possible
  • Control panel application with graphical user interface is included
  • Device status and control via private programming interface (DLL)
  • Source code of the control panel is part of the SDK.
  • DFU utility with graphical user interface is included
  • Firmware upgrade according to DFU device class
  • Customization and Multi-language user interface is possible
  • Source code of the DFU utility is part of the SDK.

NOTE: A DFU utility with identical functionality is available for macOS as well.

The SDK add-on is an optional component. It enables custom control panel development and direct access to custom firmware features. The SDK includes:

  • API definition and link library for TUSBAudio API DLL
  • API reference documentation
  • Source Code of sample control panel implementation
  • Source Code of DFU Application
Windows 10
Windows 8.1
Windows 8
Windows 7

The USB Audio 2.0 Class Driver for Windows implements the USB Audio 2.0 and 1.0 device class specification and is independent of the specific silicon and firmware solution used in a given device. As long as the hardware and firmware implement the descriptors, endpoints and requests defined in the class specification the driver should work. However, there are some requirements and assumptions as listed below.

  • A device can implement a playback data path, a recording data path, or both.
  • Both playback and recording path must be driven by the same sample clock source (as required by ASIO).
  • An Audio 2.0 device must implement at least one clock source unit. If there is more than one clock source then a clock selector unit must be implemented as well.
  • The driver supports the asynchronous, synchronous and adaptive endpoint synchronization model.
  • If there is a recording path (IN endpoint) then the driver uses the incoming sample stream as clock reference to generate the outgoing stream (playback path).
  • A playback-only device with an asynchronous OUT endpoint must implement a feedback endpoint.
  • Optionally, a device can implement a feature unit to expose volume and mute controls.

Our software is purely designed and implemented by our team in Germany - no outsourcing. Technical support is provided directly by the developers.

Current Version: 5.0

To receive a free demo, prices or license agreement, please fill out the contact form.

The free evaluation version of the TUSBAudio driver works for an interval of 60 days without any limitation. After that evaluation period has expired, the driver stops working.

Thesycon Port Devices Driver Updater

NOTE: The driver described on this page is *not for use by end users*. It will not help solve any problems you may experience with a consumer device such as a webcam, camcorder, card reader, external sound card, etc. Thesycon’s device drivers are software components intended to be used by hardware or software manufacturers to create end products.

For each USB device model an official USB vendor ID (VID) is required. Vendor IDs must be unique and will be assigned by the USB Implementers Forum ( Registration fees will be charged.

Thesycon Usb Driver


Thesycon owns a USB vendor ID and provides a subset of product IDs (PID) to licensees of Thesycon drivers.

Thesycon Port Devices Driver License Test
